Project Management V Model Requirements Architecture Design Unit Tests Integration Acceptance

About this template

This slide lays out the V-model as a V-shaped diagram, with nine colored boxes stepping down the definition side and up the test side. Dotted two-way arrows with labels connect each design level to its matching test: Unit, Integration, System and Acceptance Test Plan. The left arrow is labeled Project definition, the right arrow is labeled Project Test and Integration, and a Time arrow runs along the bottom. Use it to explain how each development phase is checked by a corresponding test phase in software and systems projects. All box labels, plan labels, colors and the title can be edited.
